Power Over Ethernet Interoperability

Complete coverage of transmitting electrical power and data over Ethernet cables

Power Over Ethernet Interoperability Guide explains how to safely transmit DC power over an existing data network cabling structure so that separate AC electrical wiring is not be needed to power up devices connected to the network. Power over Ethernet (POE) technology is a system whereby electrical safety power, along with data, is safely passed to remote devices over Ethernet cabling. Safe transmission of power over Ethernet cabling prevents overheating of the cabling, injury to users/service personnel, and damage to legacy devices that were not designed to accept voltages on the Ethernet cable. This book fully covers everything you need to know about POE.

Outlines how various devices - such as routers and RFID devices - can operate from power sent through Ethernet cables
Provides information both ends of the cable - the sourcing side (PSE) and the sinking side (PD)
Includes detailed coverage of the DC-DC switching converter - found on the PD side of the cable

Preface
Acknowledgments

Chapter 1 : The Evolution of Power over Ethernet
Chapter 2 : Overview of PoE Implementations
Chapter 3 : Detection
Chapter 4 : Classification
Chapter 5 : Inrush and Power-Up
Chapter 6 : Operation
Chapter 7 : Maintain Power and Disconnect
Chapter 8 : PoE State-Machine Diagrams
Chapter 9 : Magnetics
Chapter 10 : Isolations, PCB Design, and Safety
Chapter 11 : Surge Testing and Protection
Chapter 12 : Lab Skills, Thermal Management, and Decoupling
Chapter 13 : N-Pair Power Delivery Systems
Chapter 14 : Auxiliary Power and Flyback Design

Index
