Machine Devices and Components Illustrated Sourcebook

THE ULTIMATE COMPENDIUM OF MECHANICAL PARTS AND INGENIOUS DEVICES

This user-friendly, visual guide to parts and assemblies is an ideal working tool for anyone who designs, repairs, or operates machinery. Robert O. Parmley's Machine Devices and Components: Illustrated Sourcebook gives quick access to detailed images of hundreds of machine parts. Illustrated mechanisms include cams, gears, clutches, fasteners, housing mechanisms, and rotary and reciprocating elements.

The book features hundreds upon hundreds of components commonly used in home appliances, office machines, vehicles, aircraft, ships, construction, factory equipment, machine tools. The book also includes accompanying standards tables, design formulas, and classical analytical methods that provide additional help with selection and problem-solving challenges. No working engineer or technician will want to be without this amazing book.

HUNDREDS OF DEVICES, PLUS KEY DATA AND EQUATIONS

Mechanisms * Machine Elements * Gearing * Assemblies * Bearings with Rolling Contact * Pipes, Fittings, and Valves * Key Equations and Charts for Designing Mechanisms

Preface
Introduction

Section 1 : Ingenious Mechanisms
Section 2 : Creative Assemblies
Section 3 : Linkages
Section 4 : Connections
Section 5 : Locking Devices & Methods
Section 6 : Gears & Gearing
Section 7 : Clutches
Section 8 : Chains, Sprockets & Ratchets
Section 9 : Belts & Belting
Section 10 : Shafts & Couplings
Section 11 : Threaded Components
Section 12 : Pins
Section 13 : Springs
Section 14 : Cams
Section 15 : Grommets, Spacers & Inserts
Section 16 : Washers
Section 17 : O-Rings
Section 18 : Retaining Rings
Section 19 : Balls
Section 20 : Bushings & Bearings

Index
