Design For Manufacturability Handbook, 2nd Edition

From raw materials ... to machining and casting ... to assembly and finishing, the Second Edition of this classic guide will introduce you to the principles and procedures of Design for Manufacturability (DFM)Ñthe art of developing high-quality products for the lowest possible manufacturing cost. Written by over 70 experts in manufacturing and product design, this update features cutting-edge techniques for every stage of manufacturingÑplus entirely new chapters on DFM for Electronics, DFX (Designing for all desirable attributes), DFM for Low-Quality Production, and Concurrent Engineering.

Preface
Contributors

Section 1 : Introduction
Chapter 1.1 : Purpose, Contents, and Use of This Handbook
Chapter 1.2 : Economics of Process Selection
Chapter 1.3 : General Design Principles for Manufacturability
Chapter 1.4 : Quick References
Chapter 1.5 : The History of DFM
Chapter 1.6 : Managing DFM
Chapter 1.7 : Evaluating Design Proposals

Section 2 : Economical Use of Raw Materials
Chapter 2.1 : Introduction
Chapter 2.2 : Ferrous Metals
Chapter 2.3 : Nonferrous Metals
Chapter 2.4 : Nonmetallic Materials

Section 3 : Formed Metal Components
Chapter 3.1 : Metal Extrusions
Chapter 3.2 : Metal Stampings
Chapter 3.3 : Fineblanked Parts
Chapter 3.4 : Four-Slide Parts
Chapter 3.5 : Springs and Wire Forms
Chapter 3.6 : Spun-Metal Parts
Chapter 3.7 : Cold-Headed Parts
Chapter 3.8 : Impact- or Cold-Extruded Parts
Chapter 3.9 : Rotary-Swaged Parts
Chapter 3.10 : Tube and Section Bends
Chapter 3.11 : Roll-Formed Sections
Chapter 3.12 : Power Metallurgy Parts
Chapter 3.13 : Forging
Chapter 3.14 : Electroformed Parts
Chapter 3.15 : Parts Produced by Specialized Forming Methods
Chapter 3.16 : Metal Injections-Molded Parts

Section 4 : Machined Components
Chapter 4.1 : Designing for Machining : General Guidelines
Chapter 4.2 : Parts Cut to Length
Chapter 4.3 : Screw Machine Products
Chapter 4.4 : Other Turned Parts
Chapter 4.5 : Machined Round Holes
Chapter 4.6 : Parts Produced on Milling Machines
Chapter 4.7 : Parts Produced by Planing, Shaping, and Slotting
Chapter 4.8 : Screw Threads
Chapter 4.9 : Broached Parts
Chapter 4.10 : Contour-Sawed Parts
Chapter 4.11 : Flame-Cut Parts
Chapter 4.12 : Internally Ground Parts
Chapter 4.13 : Parts Cylindrically Ground on Center-Type Machines
Chapter 4.14 : Centerless-Ground Parts
Chapter 4.15 : Flat-Ground Surfaces
Chapter 4.16 : Honed, Lapped, and Superfinished Parts
Chapter 4.17 : Roller-Burnished Parts
Chapter 4.18 : Parts Produced by Electrical-Discharge Machining (EDM)
Chapter 4.19 : Electrochemically Machined Parts
Chapter 4.20 : Chemically Machined Parts
Chapter 4.21 : Parts Produced by Other Advanced Machining Processes
Chapter 4.22 : Gears
Chapter 4.23 : Designing Parts for Economical Deburring

Section 5 : Castings
Chapter 5.1 : Castings Made in Sand Molds
Chapter 5.2 : Other Castings
Chapter 5.3 : Investment Castings
Chapter 5.4 : Die Castings

Section 6 : Nonmetallic Parts
Chapter 6.1 : Thermosetting-Plastic Parts
Chapter 6.2 : Injection-Molded Thermoplastic Parts
Chapter 6.3 : Structural-Foam-Molded Parts
Chapter 6.4 : Rotationally Molded Plastic Parts
Chapter 6.5 : Blow-Molded Plastic Parts
Chapter 6.6 : Reinforced-Plastic/Composite (RP/C) Parts
Chapter 6.7 : Plastic Profile Extrusions
Chapter 6.8 : Thermoformed-Plastic Parts
Chapter 6.9 : Welded Plastic Assemblies
Chapter 6.10 : Rubber Parts
Chapter 6.11 : Ceramic and Glass Parts
Chapter 6.12 : Plastic-Part Decorations

Section 7 : Assemblies
Chapter 7.1 : Design for Assembly (DFA)
Chapter 7.2 : Arc Weldments and other Weldments
Chapter 7.3 : Resistance Weldments
Chapter 7.4 : Soldered and Brazed Assemblies
Chapter 7.5 : Adhesively Bonded Assemblies

Section 8 : Finishes
Chapter 8.1 : Designing for Clearning
Chapter 8.2 : Polished and Plated Surfaces
Chapter 8.3 : Other Metallic Coatins
Chapter 8.4 : Designing for Heat Treating
Chapter 8.5 : Organic Finishes
Chapter 8.6 : Designing for Marking
Chapter 8.7 : Shot-Peened Surfaces

Section 9 : Additional Developments
Chapter 9.1 : DFM for Low-Quantity Production
Chapter 9.2 : DFM in Electronics
Chapter 9.3 : DFX
Chapter 9.4 : Glossary of Terms

Index
