This is a practical guide to producing graphics for urban design projects and planning. Through illustration and narrative, the authors demonstrate how urban regeneration has inspired a growth and mixture of graphic techniques for communicating a projects vision.
The guidance includes various methods for producing hand-rendered or computer-generated visuals and details the entire planning process, from community consultations to final reports.
Introduction
Chapter 1 : Guiding Principles for Graphics in Urban Design
Chapter 2 : Graphics in The Urban Design Process (Part I)
Chapter 3 : Graphics in The Urban Design Process (Part II)
Chapter 4 : Good Technical Practice
Chapter 5 : Graphical Products in Urban Design
Chapter 6 : Managing Graphics Production
Chapter 7 : Images and Information
Illustration and Photography Credits
Further Reading
Useful Websites
