Title: Geometric Dimensioning and Tolerancing : Applications, Analysis, Gauging & Measurement (per ASME Y14.5-2018) Author: James D. Meadows ISBN: 0578470489 / 9780578470481 Format: Hard Cover Pages: 576 Publisher: James D. Meadows & Associates Inc. Year: 2019 Availability: 45-60 days
Description
Contents
This textbook reflects new symbology, rules and basic principle revisions that are contained in ASME Y14.5- 2018. It shows how to interpret design drawings and CAD representations of product definitions that use the ASME Y14.5- 2018 standard. It also explains step- by- step procedures to apply the new Y14.5- 2018 practices and allows dimensioning and tolerancing professionals to express their design requirements more clearly. The results are that: requirements are more specific in conveying functional tolerancing needs, products can be more easily manufactured, and appropriate inspection techniques are clarified.
This is one of the most comprehensive GD&T textbooks ever written by a single author. Some of the concepts covered in this text are:
All of the new symbols, rules and principles instituted by the ASME Y14.5 - 2009 Standard
Basic GD&T
Advanced GD&T
Tolerance Stack- Up Analysis
Statistical Tolerancing
Inspection Techniques and Sources of Measurement Uncertainty
Gage and Fixture Design
Tolerancing Mating Parts and Assemblies
Analyzing and Correcting Interferences, Imbalance in Rotating Parts and Material Strength Problems due to Insufficient Wall Thickness
Chapter 1 : Symbols, Rules, Charts Chapter 2 : Selecting a Tolerancing Approach Chapter 3 : Datum Feature Simulators and True Geometric Counterparts Chapter 4 : Boundaries and Material Condition Symbols, MMC, LMC & RFS Chapter 5 : Major Concepts of Geometric Dimensioning and Tolerancing Chapter 6 : Form Chapter 7 : Orientation Chapter 8 : Profile Chapter 9 : Runout Chapter 10 : Concentricity and Symmetry Chapter 11 : Datums Chapter 12 : Centerplane Datums Chapter 13 : Position with Fixed Fastener Assemblies and Projected Tolerance Zones Chapter 14 : Tolerancing Mating Parts in a Floating Fastener Assembly Chapter 15 : Direct vs. Indirect Relationships Chapter 16 : Datum Targets Chapter 17 : Datum Feature Scheme Choices Chapter 18 : Flexible Parts Chapter 19 : Position Boundary Concept Chapter 20 : Why Use GD&T Chapter 21 : Composite vs. Two Single Segment Positional Tolerancing Chapter 22 : Dimensioning and Tolerancing of Gages Chapter 23 : Tolerance Stack - Up Analysis Chapter 24 : How to be Specific in Calculating and Specifying Statistical Requirements for size and Geometric Tolerancing Chapter 25 : Tolerance Stack - Up Analysis in a 5-Part Assembly Chapter 26 : Tolerance Stack - Up Created during Manufacture due to Changing Set Ups Chapter 27 : GD&T as a Language Chapter 28 : Definitions
