Electric Power Transformer Engineering, 3rd Edition

Electric Power Transformer Engineering, Third Edition expounds the latest information and developments to engineers who are familiar with basic principles and applications, perhaps including a hands-on working knowledge of power transformers. Targeting all from the merely curious to seasoned professionals and acknowledged experts, its content is structured to enable readers to easily access essential material in order to appreciate the many facets of an electric power transformer. Topically structured in three parts, the book:

• Illustrates for electrical engineers the relevant theories and principles (concepts and mathematics) of power transformers
• Devotes complete chapters to each of 10 particular embodiments of power transformers, including power, distribution, phase-shifting, rectifier, dry-type, and instrument transformers, as well as step-voltage regulators, constant-voltage transformers, transformers for wind turbine generators and photovoltaic applications, and reactors
• Addresses 14 ancillary topics including insulation, bushings, load tap changers, thermal performance, testing, protection, audible sound, failure analysis, installation and maintenance and more

As with the other books in the series, this one supplies a high level of detail and, more importantly, a tutorial style of writing and use of photographs and graphics to help the reader understand the material. Important chapters have been retained from the second edition; most have been significantly expanded and updated for this third installment. Each chapter is replete with photographs, equations, and tabular data, and this edition includes a new chapter on transformers for use with wind turbine generators and distributed photovoltaic arrays. Jim Harlow and his esteemed group of contributors offer a glimpse into the enthusiastic community of power transformer engineers responsible for this outstanding and best-selling work.

Preface

Chapter 1 : Theory and Principles
Chapter 2 : Power Transformers
Chapter 3 : Distribution Transformers
Chapter 4 : Phase-Shifting Transformers
Chapter 5 : Rectifier Transformers
Chapter 6 : Dry-Type Transformers
Chapter 7 : Instrument Transformers
Chapter 8 : Step-Voltage Regulators
Chapter 9 : Constant-Voltage Transformers
Chapter 10 : Transformers for Wind Turbine Generators and Photovoltaic Applications
Chapter 11 : Reactors
Chapter 12 : Insulating Media
Chapter 13 : Electrical Bushings
Chapter 14 : Tap Changers and Smart Intelligent Controls
Chapter 15 : Loading and Thermal Performance
Chapter 16 : Transformer Connections
Chapter 17 : Transformer Testing
Chapter 18 : Load-Tap-Change Control and Transformer Paralleling
Chapter 19 : Power Transformer Protection
Chapter 20 : Causes and Effects of Transformer Sound Levels
Chapter 21 : Transient-Voltage Response of Coils and Windings
Chapter 22 : Transformer Installation and Maintenance
Chapter 23 : Problem and Failure Investigation
Chapter 24 : On-Line Monitoring of Liquid-Immersed Transformers
Chapter 25 : U.S. Power Transformer Equipment Standards and Processes

Index
